    Environmental Protection Hollow Fiber MBR

    Ask Lasest Price
    Brand Name : CNKHONG
    Model Number : KH-MBR-30x30
    Price : USD14/M2
    Payment Terms : L/C, T/T
    Supply Ability : 1200M2/day
    Delivery Time : within 10 days
    • Product Details
    • Company Profile

    Environmental Protection Hollow Fiber MBR

    Industrial Wastewater Biochemical Treatment MBR Membrane with PVDF 0.05 pore size


    1. MBR Introduction

    1. Membrane bioreactor is a kind of new technology for waste water treatment by combining membrane separation technique with activated sludge method ,
    2. Simple operation,high automation and modular design
    3. Save 50% occupying area compared with traditional system
    4. Relative high MLSS value(<15g/L) and long residue time for sludge (<60 days).
    5. Stable producing water quality for different inlet water.
    6. Less sludge residue reduces cost for sludge treatment,
    7. Low energy consumption,simple cleaning ad low operation cost.

    It can be used for municipal sewage and industrial waste water treatment and substitute for secondary sedimentation tank in removing suspended particles,so as to increase nitrogen removal rate and organics degradation rate.


    2. Application

    1.Domestic wastewater application.
    2. Municipal wastewater application.
    3.Food and beverage industry application
    4.Fermentation industry application
    5.Environmental protection industry

    3. Technical Parameter of Membrane Module


    Item/ModelKH-MBR-8-CO-PVDFKH-MBR-12-CO-PVDFKH-MBR-15-CO-PVDF
    Membrane Area(M2)81215
    Height1050 mm1550 mm1550 mm
    Width645 mm645mm645 mm
    Thickness47 mm47mm47mm
    Dry Weight6kgs10kgs15 kgs
    Membrane materialReinforced PVDFReinforced PVDFReinforced PVDF
    Micro pore size0.05μm0.05μm0.05μm
    ID/OD of Membrane0.9/2.2mm0.9/2.2mm0.9/2.2mm
    Suspend solid<5mg/L<5mg/L<5mg/L
    Temperature5-40℃5-40℃5-40℃
    PH range2~112~112~11
    Flux for waste water15~20 LMH15~20 LMH15~20 LMH
    Operating MethodSucking out 8 mins and staying 2 minsSucking out 8 mins and staying 2 mins

    Sucking out 8 mins

    and staying 2 mins

    Cleaning Chemicals500-3000ppm Sodium hypochlorite500-3000ppm Sodium hypochlorite

    500-3000ppm

    Sodium hypochlorite


    Item/ModelKH-MBR-25-CO-PVDFKH-MBR-30-CO-PVDFKH-MBR-35-CO-PVDF
    Membrane Area(M2)203035
    Height1550 mm1810 mm1810 mm
    Width1040 mm1040 mm1250 mm
    Thickness47 mm47mm35 mm
    Dry Weight20 kgs25 kgs30 kgs
    Membrane materialReinforced PVDFReinforced PVDFReinforced PVDF
    Micro pore size0.05μm0.05μm0.05μm
    ID/OD of Membrane0.9/2.2mm0.9/2.2mm0.9/2.2mm
    Suspend solid<5mg/L<5mg/L<5mg/L
    Temperature5-40℃5-40℃5-40℃
    PH range2~112~112~11
    Flux for waste water15~20 LMH15~20 LMH15~20 LMH
    Operating MethodSucking out 8 mins and staying 2 minsSucking out 8 mins and staying 2 mins

    Sucking out 8 mins

    and staying 2 mins

    Cleaning Chemicals500-3000ppm Sodium Hypochlorite

    500-3000ppm

    Sodium Hypochlorite

    500-3000ppm

    Sodium hypochlorite


    2. Typical parameters of MBR units.


    Item/ModelKH-MBRMD-25×20KH-MBRMD-25×25KH-MBRMD-25×30
    Quantity of MBR modules

    20 pcs of

    MBR-25 modules

    25pcs

    MBR-25 modules

    30 pcs

    MBR-25 modules

    Total Membrane Area(M2)500625750
    Length1550 mm1875 mm2200 mm
    Width1255mm1255 mm1255 mm
    Height2000 mm2000 mm2000 mm
    Estimated Weight750 kgs940 kgs1125 kgs

    Item/ModelKH-MBRMD-30×40KH-MBRMD-30×45KH-MBRMD-30×50
    Quantity of MBR modules

    40 pcs of

    MBR-30 modules

    45 pcs

    MBR-30 modules

    50 pcs

    MBR-30 modules

    Total Membrane Area(M2)120013501500
    Length2850 mm3175 mm3500 mm
    Width1255mm1255 mm1255 mm
    Height2200 mm2200 mm2200 mm
    Estimated Weight1680 kgs1800 kgs2000 kgs

    4.. Structure of Membrane Modules and Frames:


    A. Structure of MBR Modules


    B.Structure of MBR Frames


    5. Product Features


    -- All the frames are made of SS 304 or SS 316 stainess steel with reliable frames.

    -- Every modules can be pulled out or putted in very conveniently for they are installed into UPVC Groove from top to bottom.

    -- Every modules have flexible tubes connecting to collecting pipes.

    -- Every modules have independent air blowing tube. There are additional air-blowing tube at the bottom of the frames.

    -- All the modules have an added patented design air blowing tube to enhance the efficiency of the air blowing onto the membrane surface.

    -- Permanent Hydrobility Membrane

    -- Strong strength, the broken strength more than 50MPa

    6. Application of MBR Units:

    The whole installation and application process of our MBR modules are described as the following photo:




    Why Choose US?


    1). Over 20 years experience in UF and MBR membrane
    2). Excellent cooperation partner
    3). Own an excellent technical team
    4). Advanced R & D capability
    5). International management system(ISO9001)
    6). Located in Jiangsu, convenient for export transportation.


    Our Service


    1). MBR membrane technical consulting,
    2). MBR membrane application engineering design,
    3). MBR system manufacturing, installation and commissioning,
    4). Different membrane dimension, material like PP, PVDF etc.,can be customize according to your requirements
    5). 12 months warranty
